| Conductor |
1.0mm (32/0.20mm) Annealed plain copper stranded high flexibility |
| Cores |
7 - Black (numbered) plus 1 Green/Yellow Earth |
| Insulation |
SPVC V-75. |
| Sheath |
SPVC Grey – as standard colour |
| Nominal O.D (mm) |
8.0mm |
| Installed Temp Rating |
Fixed -20°C to 80°C / Flexing -5°C to 80°C |
| Min. Bend Radius |
Fixed 7.5 x cable diameter / Flexing 15 x cable diameter |
| Max Operating Voltage |
Uo 318v. AC |
| Rated Voltage |
Uo/U 300/500v |
| Max. Conductor Temp in Service |
80°C (Current ratings are based on 30°C air temp) |
